The 1336-BDB-SP34C is a grid-driven circuit board manufactured by Rockwell Automatics under the Allen-Bradley brand for use in its 1336 series of inverters. This board is designed for the 1336 Plus, Impact and Force AC drivers
It has the following characteristics:
The rated AC voltage is 460 volts for a power output of 15 HP
The operating temperature range should be between 0 and 50 degrees Celsius
The gate drive PCB is placed near the main control board of the host 1336 driver, making it easy to install and compact in size
Fully compatible with the 1336 Plus, Force, Impact, and other drive families
The drive features torque and speed regulation and a motor control algorithm that provides excellent torque regulation at low speeds
Equipped with an IGBT braking system that uses regenerative energy, it can operate without expensive chopper circuits
The 1336-BDB-SP34C PCB can be used as the power amplification unit of the host driver, converting the low power input to the high power input, which is transmitted to different parts of the driver
Meets all specifications required by EMC standards, with different logic levels connected to the SCR gate
During PCB replacement, the operator must use a grounded wrist strap to avoid electrostatic discharge and protect the sensitive parts of the gate drive PCB
In addition, the 1336-BDB-SP34C gate driver plate is a replacement part of the Allen-Bradley 1336 (Force, Impact, Plus, Plus II and REGEN) drive assembly family, And can be used as a suitable replacement for 1336-BDB-SP37-A/B board
It is particularly suitable for E-Frame 1336 drives, which have a 460 volt AC voltage rating and 150 HP output rating
This drive board is widely used in power, oil, mine, port, heating, gas, water supply, sewage treatment, metallurgy, paper, textile, chemical, water conservancy and other modern industrial fields
