1336-L5 24 VDC/24 VAC logic board for receiving additional external contact closure signals
The 1336-L5 control interface board has the following features:
24 VDC/24 VAC logic board for receiving additional external contact closure signals.
With twelve screw type terminals, designed for terminating wire sizes 2.1 and 0.30 mm² (14 and 22 AWG) copper wire.
Terminals 19 and 20 are used for start/stop functions only, terminals 19 can be programmed to accept status, run, forward, and start inputs, while terminals 20 can be configured to stop/fault reset signals.
Supports 2-wire and 3-wire control cable configuration.
Other commands including acceleration, deceleration, synchronization, and traverse can be controlled
Email:18005021035@163.com
Phone:+86 18005021035
Name:BeiLin
Content details
Product introduction:
The 1336-L5 is a control interface board manufactured by Allen-Bradley (Rockwell Automation) as part of the 1336 family of adjustable AC drives. This control interface board is designed to work with the 1336 Plus, 1336 Force, and 1336 Impact drives, especially frame A-H drives (except frame C drives rated at 25 HP and 30 HP).
The 1336-L5 control interface board has the following features:
24 VDC/24 VAC logic board for receiving additional external contact closure signals.
With twelve screw type terminals, designed for terminating wire sizes 2.1 and 0.30 mm² (14 and 22 AWG) copper wire.
Terminals 19 and 20 are used for start/stop functions only, terminals 19 can be programmed to accept status, run, forward, and start inputs, while terminals 20 can be configured to stop/fault reset signals.
Supports 2-wire and 3-wire control cable configuration.
Other commands including acceleration, deceleration, synchronization, and traverse can be controlled
In addition, the 1336-L5 control interface board can also be used to achieve accurate control of the motor, including smooth start and stop of the motor, speed and torque regulation, and has overcurrent, overload, overvoltage, undervoltage, short circuit and other protection functions to ensure the safe operation of the equipment. It has an IP20 protection rating and is suitable for dry, non-corrosive gas and dust-proof environments
1336-L5 control interface board is widely used in machinery manufacturing, textile, food, packaging, printing and other fields, can be compatible with A variety of A-B equipment, provide reliable control interface, and easy to install and use
