★★★Product detail：

The Woodward MicroNet 5200 CPU module 5503-325 plugs into the MicroNet Plus/Simplex chassis, and there is only one of these modules for a 2-rack configuration. The module can be removed and inserted in real time from the MicroNet Plus case.

Technical specification
Brand Woodward
Humidity standard UK Lloyd’s (20-55 °C, 95%RH non-condensing, 2 cycles, over 48 hours)
Part number 5503-335
The maximum altitude is 4000 meters
Operating temperature 0 to +55 °C (+32 to +131 °F)
Overpressure rating Cat 2
Protection level IP20 as defined in IEC 529
Sound level less than 70 decibels
Storage temperature – 20 to +45 °C (- 4 to +113 °F)

Information about 5503-335

The 5503-335 module was one of the last 5200 cpus in the MicroNet family. The module has 64 megabytes of flash memory and 128 megabytes of RAM; The module will also operate at 400 megahertz. A key feature of the module is that when used with a Power PC, it offers a high processor and has CAN, live networking, and Ethernet ports. This model has an operating temperature limit of negative 40 degrees Fahrenheit to positive 185 degrees Fahrenheit.

5503-335

Since the motherboard will be considered a CPU-based system, the 5503-335 must be used with an expansion chassis with a remote RTN module. There are ten leds on the front panel, as shown below:
TX/RX
LINK
STANDBY
SYSCON
RUN
IOLOCK
LVCC WATCHDOG
CAN #1, #2
FAULT

Each LED has a different function. The FAULT LED will appear red and indicate CPU failure by flashing red. Usually, the IOLOCK LED will also light up red, indicating that the VMEbus or the CPU itself has an I/O LOCK condition.

The Type 5466-1035 is designed for the MicroNet family. The device is designed to be used as the CPU5200 with a PowerPC MOTOROLA MPC5200 processor. One of the main features of the device is that it can be used in redundancy or simplex mode. When the device is used in a redundant configuration, there is a second CPU, which will be located in slot 14 or 8, depending on the chassis configuration being used.

The 5466-1035 model has a variety of features, including but not limited to a universal Ethernet port, a service port, 64 MB flash memory, and a real-time clock. Even if the controller is turned off, the real-time clock runs on the battery and the user cannot replace the battery. Unfortunately, there aren’t any real-time networking (RTN) ports available on this model, which means this CPU doesn’t support extended chassis operation. If the CPU is not configured for use in RTN mode, a single Ethernet port will not be active.
