Product introduction：

The 81943A041-1 is a precision amplifier module from ABB that provides the following features and applications:
High precision amplification: The module has high precision amplification performance for applications requiring high precision measurement and control, reducing error and distortion
Multi-channel support: usually support multiple input channels, can process multiple signals at the same time, improve the parallel processing ability of the system
Customizability: According to the specific application requirements, the amplifier module can be customized, such as adjusting the magnification, setting the input and output range
High reliability and stability: The use of high-quality components and materials, through strict quality control and testing, to ensure long-term stable operation
Analog input and output: with analog input and output functions, support single-ended analog input, resolution of 16 bits, sampling rate of up to 100KSPS, input signal range of 0 to 5V or 4 to 20mA; The analog output resolution is 12 bits and the output signal range is 0 ~ 5V or 4 ~ 20mA
Real-time Clock (RTC) : RTC function with spare lithium battery
Applications: Widely used in control systems, monitoring systems and data acquisition systems to improve signal quality and promote accurate processing, analysis or transmission

DSDI110AV1 3BSE018295R1 is a digital input board produced by ABB. It plays an important role in industrial automation system. The main features and applications are as follows:
Digital signal conversion: The digital input board has the function of converting digital signals to analog signals for easy transmission to analog devices or actuators to control production processes or other operations
Modular design: The structure of the product is modular, easy to install and replace, improve the flexibility and maintainability of the system
Multi-channel input: Support up to 32 channels of digital input, each port can receive digital signals
High precision and security: The design has high precision digital input capabilities and includes alarm and protection functions
Communication interface: With a communication interface, you can exchange data with other systems or devices
Applications: Widely used in industrial automation systems, such as manufacturing, power, oil and gas, chemical and other fields
In addition, the DSDI110AV1 3BSE018295R1 has the following features:
4-channel digital input, response time is less than 2 ms, safety level reaches SIL 2/Ple, in accordance with IEC 61508, IEC 60947-5-5 certification standards
Small in size for easy DIN rail installation and designed to be used without programming, it is suitable for receiving signals from safety sensors or switches and converting them into signals that are recognizable by the safety controller

The DSAI130D 3BSE003127R1 is an analog input board manufactured by ABB with the following features and applications:
16 analog input channels: Each input channel is capable of measuring a variety of signals and is suitable for a variety of application scenarios
4 groups of filtering times: allows selection of different filtering options based on specific application requirements
12-bit resolution: provides high precision analog signal measurement
Differential input: The ability to measure the difference between two input signals with an input range of +/-10V and +/-10mA
Conversion time: 0.03% conversion time to ensure fast response
Cut-off frequency: Multiple options are available (10Hz, 30Hz, 100Hz, 300Hz), allowing selection based on the frequency of the signal under test
Compact dimensions: 365 mm x 20 mm x 261 mm, light weight (0.475 kg), suitable for a variety of installation options in industrial environments
Compliance with the RoHS Directive: comply with the provisions of EU Directive 2011/65/EU on the restriction of hazardous substances and fall within WEEE Category 5, i.e. small equipment with an external dimension of no more than 50 cm
In addition, the analog input board is well designed, provides efficient and reliable data acquisition and processing capabilities, has strong flexibility and real-time, and can collect and transmit data in real time to ensure that the control system obtains and responds to the field status in time
Modules are designed to be easy to maintain and replace, reduce operating costs, and may have fault diagnosis and condition monitoring capabilities to help prevent potential failures and maintenance, ensuring safe operation of the system

About Chengdu Sunshine Xihe Electric Co., Ltd

Chengdu Sunshine Xi He Electric Co., Ltd. specializes in selling the world’s major electrical brand products overseas direct procurement,

genuine inventory, price preferential after-sales warranty, complete models, the same product, not the same price and service.

Large supply of original imported DCS system accessories, PLC system accessories.

Main :ABB, GE Fanuco, Bentl Bentley, Triconex Invensys, Woodward Woodward, Foxboro, Foxboro,

Westinghouse /Emerson, Reliance Ryan, SchneiderModicon, A-B, HIMA dark horse, Motorola MOTOROLA,

Kollmorgen Kollmorgen Bosch/Rexroth/ Bosch Rixon, NI,YOKOGAWA Yokogawa, and other major brands of DCS system accessories,

robot system accessories, large servo system discontinued spare parts.
