Weight:0.5 kg

Dimensions (L x W x H):100mm x 100mm x 25mm

Operating Voltage:24 VDC

Input Current:10 mA

Output Current:20 mA

Communication Interface:Profinet

Operating Temperature Range:-25°C to +70°C

Environmental Compliance:UL, CE

    The ABB DSQC563 Brake Release Board is meticulously engineered to enhance operational efficiency in industrial automation environments. Its compact size allows for easy integration onto DIN rails, minimizing installation time and complexity.

    Equipped with simplified wiring connections, this board ensures a straightforward setup process, reducing the risk of errors during assembly. The board is designed with a high degree of reliability, making it suitable for continuous operation in demanding industrial conditions.

    Featuring a robust construction that can withstand a wide range of temperatures (-25°C to +60°C), the DSQC563 is capable of operating under diverse environmental conditions. Its lightweight design (0.1 kg) further aids in efficient transportation and handling.

    The board offers two input terminals, enabling the connection to various sensors or switches for monitoring brake states. This functionality ensures real-time feedback on the status of brakes, facilitating timely intervention in case of any issues, thus preventing potential safety hazards and downtime.

    With its adherence to international standards and stringent quality control measures, the ABB DSQC563 Brake Release Board is a trusted solution for enhancing safety and productivity in a multitude of industrial applications. Whether in manufacturing lines, material handling systems, or other critical operations, this board delivers unparalleled performance and reliability.
