Operating Supply Voltage:24VDC

Input Channels:8 Current Sinking Safety Inputs

Output Channels:8 Current Sourcing Safety Outputs

Operating Temperature Range:-20°C to +70°C

Communication Interface:Modular, Interchangeable

Dimensions:3.03 x 0.98 x 2.17 inches

Weight:2.2 ounces

    The Rockwell Automation 1738-IB8M8 Analog Input Module is a versatile and robust solution for industrial automation environments. Its ability to handle a wide range of input signals makes it suitable for applications requiring precise measurement and control over various processes. With its eight-channel design, this module allows for the efficient integration of multiple sensors, enhancing system flexibility and performance.

    Designed with industrial-grade components, the 1738-IB8M8 ensures reliability and durability in harsh working conditions. Its compatibility with Rockwell’s ControlLogix and CompactLogix series PLCs ensures seamless operation within existing control systems, reducing integration complexities and enhancing productivity.

    Featuring advanced signal conditioning technology, the module accurately converts analog inputs into digital signals, enabling precise control and monitoring functions. The integrated communication interface supports both serial protocols, facilitating easy data transfer between the module and the PLC, or other devices in the network.

    The module’s IP20 enclosure rating provides protection against dust and light splashes, ensuring operational safety in industrial settings. Its compact size and panel-mounting capability make it ideal for space-constrained applications, allowing for efficient installation and management within control panels.

    The 1738-IB8M8 is equipped with LED indicators for quick status verification, providing visual feedback on power supply, input signal presence, and potential errors. This feature aids in quick troubleshooting and maintenance, minimizing downtime and enhancing operational efficiency.
