Model Type:SLC500

Model Number:1746-NIO4V/A

Manufacturer:Allen Bradley

Module Type:Analog Combination Module

Resolution:High Resolution

Input Channels:2

Output Channels:2

Input Voltage Range:-20 to 20 V

Absolute Input Voltage:+/- 7.5 VDC or 7.5 VAC RMS (Maximum)

Input Current Range:-20 to 20 mA

Absolute Input Current:-30 to 30 mA (Maximum)

Output Range:-10 to 10 V – 1 LSB

Full Scale Output:10 VDC

Overvoltage Protection:7.5 VAC RMS

Output Voltage Range:-10 to 10 VDC – 1 LSB

Backplane Current Draw:55 mA

    The Allen Bradley SLC500 1746-NIO4V is a versatile and reliable solution for industrial automation and control systems. This high-resolution analog combination module is designed to provide accurate and consistent performance in demanding environments. With two input channels and two output channels, it can efficiently manage a wide range of analog signals. Its robust design ensures long-term reliability and minimal maintenance, making it an excellent choice for applications requiring precise control and monitoring. The module supports a common mode voltage range of -20 to 20 V and an absolute input voltage of +/- 7.5 VDC or 7.5 VAC RMS, ensuring compatibility with various sensors and devices. The output range of -10 to 10 V offers high precision, and the overvoltage protection feature of 7.5 VAC RMS safeguards the system from potential damage. The Allen Bradley SLC500 1746-NIO4V is easy to integrate into existing control systems and comes with a low backplane current draw of 55 mA, making it an energy-efficient option. Upgrade your industrial control system today with this reliable and precise analog I/O module.
