The AM80A-150L-065F33 is a non-isolated point-of-Load (PoL) DC converter module produced by Artesyn/Advanced Energy with an output power of 240 watts and an output voltage of 6.5 volts. The module is designed to operate over a wide input voltage range of 90V to 200V and is capable of delivering up to 33A output current.

The main features of the AM80A-150L-065F33 include:
Single output
Input voltage range: 90-200 VDC
Output voltage: 6.5V
Output current: 33A
Power: 240W
Efficiency: 84% typical value (5V @ 40A)
Load adjustment rate: 0.1% typical (no load to full load)
Line adjustment rate: 0.02% typical value
Ripple/Noise: 50 mV typical (output below 5V)
Remote sensing function
Overvoltage protection
Current limitation
With enable, voltage adjustment, current limit adjustment, clock input/output, power supply good, temperature monitoring, current monitoring and overvoltage protection adjustment and other control functions

In addition, the AM80A-150L-065F33 also has the following features:
1MHz fixed frequency
100°C Substrate operating temperature (no derating required)
Low output ripple and noise
Excellent transient response
Securely isolated low voltage interface with ALP linear control
High reliability – over 1 million hours MTBF
Wide input voltage range
The AM80A-150L-065F33 module is suitable for a variety of applications including industrial, telecommunications, medical and military, providing solutions with high power density and high efficiency.
