DS200PCCAG9A technical specifications
Manufacturer GE General Electric
Series Mark V
Function Product number DS200PCCAG9A
Function Description Power card component
Instruction Manual GEI-100161
Functional acronyms PCCA Corporation
Armature voltage regulation 240-630 V regenerative voltage
Feature revision 1 One

About DS200PCCAG9A
The GE DC power connection board DS200PCCAG9A is used as an interface between the driver and the SCR power bridge in its manually specified Mark V series. The DS200PCCAG9A board cannot be repaired because there are no repairable parts on it. This means that if it is defective, you have to replace it with a new board. However, there are some steps you can take to verify that the board is defective before calling the service. First, you can stop the larger Mark V Series drive from the control panel. The keys on the keyboard enable you to start and stop the motor command. In addition, stop all power to the drive by unplugging the fuse from the three-phase power supply. Go into the circuit boards in the circuit board cabinet and make sure that all the cables and wires connected to the board are fully engaged by pulling them and pressing them against the connectors on the board. You can also check the drive’s diagnostic report. Diagnostic reports can be accessed from the control panel. You can access application parameters from a series of menus. Use the keys on your keyboard to move around the menu. A specific menu option displays the full diagnostic report on the drive.

While it is certainly useful to know the service requirements of your DS200PCCAG9A power connection card component based on a diagnostic report, it is also critical to know the various hardware elements and specifications useful for its assembly. One major highlighted hardware feature of this DS200PCCAG9A power connection card must be identified as its total of four hardware jumpers, each labeled JP1 through JP4. These hardware jumpers are included in the components of this GE product for the power bridge and voltage feedback channel connections of the buffer capacitors of this Mark V Series product. The armature voltage rating of this particular DS200PCCAG9A power connection card depends on the series group number in its DS200PCCAG9A functional product number; Whereas this DS200PCCAG9A power connection card assembly has Mark V Series Group 9 series group, its armature voltage rating is 240-360 volts of regenerative voltage.
