The IOR810 is an industrial control module produced by ABB. The details are as follows:
Industrial control module: IOR810 is mainly used in industrial automation control systems to achieve the control of various equipment, such as motors, valves, actuators, etc., with versatility, reliability, and easy integration
Operating voltage and output frequency: The module’s operating voltage is 220V and the output frequency is 50kHz
S800 I/O Gateway Module: The IOR810 is also an S800 I/O gateway module for connecting the S800 I/O subsystem to the Symphony Plus controller, with a maximum connection distance of 15 meters (fiber) or 100 meters (cable) via fiber or cable connection. Data transfer rate up to 10 Mbps, operating temperature range -20°C to 60°C, protection level IP65
Connection capability: The IOR810 gateway module can connect up to seven S800 cluster modems, each supporting up to twelve S800 I/O modules, connecting Symphony Plus controllers and S800 I/O modules via the ModuleBus, supporting both digital and analog signal types, It can be configured in redundant or non-redundant mode
Design standards: comply with a number of safety and environmental standards, such as CSA C22.2 No. 142, EN 60068-2-1, etc., suitable for chemical, electric power, pharmaceutical, water treatment and other industries in the automation control system
Installation and maintenance: Supports hot swap for easy maintenance and replacement. You can configure and diagnose modules through configuration software
Product size and weight: Product size is 91.44 mm (net depth/length), 243.84 mm (net height), 190.5 mm (net width), product weight is 0.431 kg
High performance: With its high performance, flexible configuration, high reliability and easy maintenance, the IOR810 is suitable for industrial automation applications that require high-speed data exchange, reliable communication and seamless integration
SOE function: Supports the Event sequence (SOE) function to provide accurate time stamps
Data scanning: The IOR810 scans the S800 I/O module and provides information to the Symphony Plus controller via the HN800
