The RLX2-IFH24E is an industrial-grade 2.4GHz wireless repeater from ProSoft Technologies, designed for applications such as industrial automation and robotics that require long distance, fast and reliable communication. It has the following features:
Operating frequency: 2.400 GHz to 2.4835 GHz, within the international license-free 2.4 GHz bandwidth.
Data rate: Up to 1.1 Mbps.
Output power: Adjustable from 100 mW to 1W.
Reception sensitivity: -98 dBm at 1.1 Mbps and -106 dBm at 345 kbps.
Power supply range: 10-30 VDC.
Operating temperature: Standard from -25°C to +70°C, extended to -40°C to +65°C.
Network structure: Supports point-to-point (PTP) and Intelligent Ethernet (SSE) modes.
Transmission distance: Up to 15 miles in PTP mode using a high-gain antenna.
Security: Proprietary frequency-hopping algorithm and 128-bit AES encryption algorithm are used to ensure secure data transmission.
Configuration and Monitoring: Quick configuration via ControlScape software, including OPC server software, allows monitoring of network status via OPC client software.
The RLX2-IFH24E industrial repeater is widely used in industrial automation, robotics, process control, remote monitoring, intelligent transportation systems, building automation and smart home scenarios, providing stable and reliable wireless communication solutions. It has also received several certifications, including ATEX, cULus, FCC, Gost-R, IC and UL/cUL: Class 1, Div 2, ensuring its safety and compliance in a variety of industrial environments.
