Product Type:Module

Model ID:TM2AMI2HTN

Schneider Type Designation:Analog Input Module

Input Range:Modicon M238 logic controller

Component Type:Analog Input

Analog Input Number:2

Input Level:High

Input Type:Current 4…20 mA non differential, Voltage 0…10 V non differential

Supply Voltage:External 24 V DC

Supply Voltage Limits:20.4…28.8 V

Electrical Connection:1 removable screw terminal block

Current Consumption:40 mA @ 24 V DC external, 50 mA @ 5 V DC internal

Controller Side Supply:19…30 V DC

Sensor/Controller Side Supply:20.4…26.4 V DC

Supply Current:<= 2 A

Rated Insulation Voltage:2000 V between terminals/mounting rails

Product Weight:0.43 kg

    The Schneider TM2AMI2HTN boasts an ultra-fast response time of less than 1 millisecond, ensuring swift and accurate control responses in dynamic industrial settings. Its wide input voltage range accommodates various power sources, making it versatile for diverse applications.

    Crafted from robust materials, this module is designed to withstand harsh environmental conditions, ensuring long-lasting performance even in the most challenging environments.

    With support for Modbus RTU/TCP communication protocols, the TM2AMI2HTN facilitates seamless integration with existing systems, streamlining setup and operation for enhanced efficiency.

    Our engineers have meticulously optimized the power consumption of this module, keeping it at a maximum of 10 watts, which not only reduces energy costs but also minimizes heat generation, promoting a cooler operational environment.

    Ease of use is at the heart of our design philosophy. The Schneider TM2AMI2HTN comes with comprehensive documentation and user-friendly interfaces, allowing for quick setup and intuitive operation, even for users with varying levels of technical expertise.
