Type:Rotary Limit Switch

Product ID:XCK-J-H29

Movement:Rotary

Number of Poles:1

Contacts Configuration:1 NC/NO

Electrical Connection:Screw-clamp terminals, 1 x 0.34…2 x 1.5 mm²

Rated Operational Current:3 A at 240 V, AC-15, A300 EN/IEC 60947-5-1 Appendix A

Contact Rating:0.27 A at 250 V, DC-13, Q300 EN/IEC 60947-5-1 Appendix A

Net Weight:1.07 lb (0.485 kg)

    Designed for industrial environments, the Schneider XCK-J-H29 Limit Switch offers a robust solution for ensuring the safe operation of machinery. Built with a thermoplastic round rod lever, this switch can be actuated by any moving part within its range, making it highly versatile. Its screw-clamp terminals ensure secure electrical connections for wires ranging from 0.5mm² to 2.5mm², providing flexibility in installation. The switch body is made of plastic, offering durability and resistance to wear and tear. With two poles and one normally closed (NC) and one normally open (NO) contact, it meets a variety of control needs. Rated for up to 3A at 240V AC and 0.27A at 250V DC, this switch is capable of handling a wide range of operational currents. Its lightweight design makes it easy to integrate into existing systems without adding unnecessary bulk.
