Type:Analog Input Module

Sub-Type:ET 200SP

Module Number:6ES7 134-6JD00-0CA1

Channel Count:4

Temperature Range:-200°C to +850°C

Precision:+/- 0.1%

Wiring Options:2-, 3-, 4-wire

Color Code Compatibility:A0, A1, CC00

Bit Resolution:16-bit

Communication Protocol:Integrated

Fault Diagnosis:On-board

Operating Voltage:10VDC

Current Consumption:Max. 20mA

Operating Temperature:-25°C to +60°C

Storage Temperature:-40°C to +85°C

Mounting Style:Panel

Weight:Approx. 0.037 kg

Dimensions:15mm width x 70mm height x 25mm depth

    Integrating advanced technology from Siemens, the 6ES7134-6JD00-0CA1 Analog Input Module is engineered for seamless integration into complex industrial automation systems. This module boasts an impressive 4-channel configuration, designed to accurately convert a wide range of temperature signals from RTD and thermocouples.

    Featuring an accuracy of ±0.1%, it ensures unparalleled precision in signal conversion, crucial for applications requiring high levels of measurement accuracy. The flexibility of supporting 2-, 3-, and 4-wire configurations accommodates various installation scenarios, ensuring compatibility with a broad spectrum of industrial environments.

    Channel diagnostics feature empowers users with real-time monitoring capabilities, enabling quick identification and resolution of potential issues, thus enhancing system reliability and uptime. With a compact size and lightweight design, the module optimizes space and facilitates easy installation.

    This module is specifically compatible with BU types A0, A1, and CC00 color codes, ensuring seamless integration into existing Siemens SIMATIC ET 200SP systems. The inclusion of 16-bit resolution provides enhanced data processing capability, catering to the needs of demanding industrial applications.

    The 6ES7134-6JD00-0CA1 is equipped with a built-in EMI filter for 230V 1 phase / 460V 3 phase, ensuring robust performance in noisy industrial settings. It supports flexible extension options, allowing for scalable system design and easy future upgrades. Moreover, it offers complete protection against common industrial hazards, ensuring longevity and reliability.
