Model Number:6FC5357-0BB25-0AA0

Processor Type:32-bit RISC Processor i960SB

Floating Point Unit:Integrated

Operating System Memory:FLASH

Function Software Memory:Battery-backed SRAM

Drive Interface:1x Analog Interface (+/-10V)

Measuring System Interfaces:4x 1-Position Encoders (Incremental Position Measurement/SSI)

PCMCIA Card Slot:1x

Digital Inputs:(4) 24V DC

NC READY Output:1x

Probe Capacity:up to 2

Electronic Handwheels:up to 2

Housing Type:S7-300

Power Supply:Integrated 24V DC

    The Siemens SINUMERIK 6FC5357-0BB25-0AA0 CNC Control Module boasts a 32-bit RISC processor, i960SB, which ensures fast processing speeds and efficient operation. The inclusion of an integrated floating point unit significantly enhances its computational capabilities for complex tasks.

    Equipped with battery-backed SRAM memory for storing part programs and non-volatile data, this module ensures reliable operation even during power outages. The integrated Flash Memory supports the operating system and function software, providing a robust foundation for automation tasks.

    With up to 4 drive interfaces for Analog Interface (+/-10V) and up to 4 Stepping Motor Drives, this control module offers flexibility and compatibility across various drive systems. The connection options for 1-Position Encoders via Incremental Position Measurement or SSI provide precise control over motion.

    The presence of a PCMCIA card slot facilitates expansion and customization according to specific application requirements. The module features 4 x 24V DC digital inputs, supporting P-Switching, ensuring compatibility with a wide range of input devices. Additionally, it includes an NC READY output and support for up to 2 probes and electronic handwheels, enhancing its usability in diverse manufacturing environments.

    Designed for integration into S7-300 housing, the Siemens SINUMERIK 6FC5357-0BB25-0AA0 CNC Control Module offers a compact and efficient solution for industrial automation. The integrated 24V DC power supply ensures stable operation without the need for external power sources, further simplifying installation and maintenance processes.
