The SK-H1-ASICBD-D1030 is an application-specific integrated circuit board manufactured by Allen-Bradley (Rockwell Automation) for digital signal processing in industrial control and automation systems. This ASIC board is part of the PowerFlex 700 series and has a current rating of 1030 amps for applications with a voltage class of 400/480 volts AC. It is compatible with the PowerFlex 700 H and PowerFlex 700 S series and enables the functionality of a wide range of electronic components, including resistors, capacitors, inductors, diodes, transistors, and more, on a single integrated circuit

The board is used to regulate the torque and speed of the three-phase induction motor and drive, in conjunction with the host PowerFlex inverter, which is equipped with advanced motor control algorithms to provide fast start, process PI control and inertial traverse. In addition, the SK-H1-ASICBD-D1030 ASIC board features an open housing design with an internal fan of 60 mm size for internal cooling and is connected to the fan inverter and other components via cables of different sizes

In addition, the product has multiple communication interface support, including RS232, RS485, and CAN, supporting up to 16 digital inputs and outputs, 4 analog inputs and outputs, 4 PWM outputs, and 3 timers. These characteristics make it suitable for industrial automation, robot control, intelligent warehousing and logistics equipment

During installation and use, ensure that the ambient temperature is between 0 and 60 degrees Celsius to ensure the normal operation of the driver and the circuit board, and pay attention to the minimum internal bending radius of the cable during the process of 25.4 mm to avoid damage
