Frequency Range:250 kHz to 1 GHz

Output Power:-10 dBm to +13 dBm

Waveform Types:Sine, Square, Triangle, Pulse

Amplitude Accuracy:±0.5 dB

Phase Noise:-90 dBc/Hz at 10 kHz offset

Harmonic Distortion:-70 dBc typical

Output Impedance:50 Ohms

Voltage Standing Wave Ratio (VSWR):1.5:1

    The Tektronix 5B12N Arbitrary Function Generator is designed to meet the demanding requirements of modern industrial control systems. With its broad frequency range from 1 µHz to 50 MHz, it can generate a variety of waveforms including sine, square, triangle, ramp, pulse, noise, and arbitrary signals. The generator’s amplitude resolution of 1 µVpp to 10 Vpp ensures precise control over signal strength, making it suitable for a wide range of applications.

    One of the standout features of the 5B12N is its spectral purity, which typically achieves -90 dBc at a 1 kHz offset. This ensures minimal harmonic distortion, leading to highly accurate signal generation. Additionally, the phase shift capability of ±10° at 50 MHz provides flexibility in creating complex waveforms.

    The generator supports memory depths up to 16 kpts, allowing for extensive waveform storage and recall. Its user-friendly front-panel controls make operation straightforward, while connectivity options such as USB and LAN enable easy integration with other systems and data transfer.

    Designed with durability and reliability in mind, the 5B12N features robust construction and reliable performance. Whether you are testing electronic circuits, calibrating sensors, or performing research and development, the Tektronix 5B12N Arbitrary Function Generator is an indispensable tool for achieving precision and accuracy.
