VMIVME-2170A: VME bus module with superior performance
summarize
The VMIVME-2170A is a VME bus module designed for harsh industrial environments and high-end scientific applications. It meets the most demanding technical requirements with excellent performance, powerful data processing capabilities and high reliability.

peculiarity
High-performance processor: Integrates high-performance multi-core processors to provide fast response and data processing capabilities.
VME bus compatibility: VME64 and VME64e standards are supported to ensure compatibility with existing systems.
Multifunctional I/O interface: Provides a variety of high-speed I/O interfaces to meet different data transmission requirements.
Modular expansion: Supports modular expansion, which is easy to customize according to application requirements.
Industrial-grade durability: Designed to withstand extreme temperatures and harsh environments for long-term stable operation.
Technical specification
Processor: Intel Xeon E-2288G, 3.7GHz base frequency, Max Rui 4.8GHz.
Memory: DDR4 2933MHz ECC SDRAM, supports up to 64GB.
Storage:
2.5-inch SATA III SSD with a maximum capacity of 4TB.
M.2 NVMe SSD slot, supporting PCIe 3.0 x4 ports.
VME bus: Supports VME64 and VME64e bus standards, providing 64-bit data width and up to 33MHz transfer rate.
I/O interface:
Two 10/100/1000 Mbps Ethernet interfaces
Four USB 3.1 Gen 1 ports
2 RS-232 serial interfaces
1 RS-422/485 serial interface
Display: DVI-D interface, support 1920×1200 resolution.
Power Supply: AC 100-240V, 50/60Hz, DC 24V.
Environmental requirements:
Operating temperature: -40°C to +85°C
Storage temperature: -55°C to +125°C
Vibration: 5g, 10-500Hz
Impact: 20g, 11ms
Application field
The VMIVME-2170A is suitable for applications that require high performance computing and data acquisition, such as:

Aerospace: Data processing for satellites and flight control systems.
Military and defense: Signal processing for radar and communication systems.
Scientific research: Used for physics experiments and data analysis.
Industrial automation: for robot control and production monitoring systems.
