VMIVME-4150: High performance VME bus module
summarize
The VMIVME-4150 is a high-performance VME bus module designed for high-speed data processing and complex computing tasks. It uses advanced technology to deliver unmatched computing power, data transfer speeds and system reliability for demanding industrial environments and research applications.

peculiarity
Powerful processor: The latest high-performance processor is built in to ensure fast processing of large amounts of data.
Full VME compatibility: Support for VME64 and VME64e standards ensures seamless compatibility with existing systems.
Flexible expansion capability: Multiple expansion slots are available to support a wide range of VME bus modules.
Industrial-grade durability: Designed to withstand extreme temperatures and harsh environmental conditions for long-term stable operation.
Rich I/O interfaces: Provides a variety of high-speed I/O interfaces to meet different data transmission and device connection requirements.
Technical specification
Processor: Intel Xeon E-2186G, 3.8GHz base frequency, maximum Rui frequency 4.0GHz.
Memory: DDR4 2666MHz ECC SDRAM, supports up to 256GB.
Storage:
2.5-inch SATA III SSD with a maximum capacity of 8TB.
M.2 NVMe SSD slot, supporting PCIe 3.0 x4 ports.
VME bus: Supports VME64 and VME64e bus standards, providing 64-bit data width and transfer rates of up to 66MHz.
I/O interface:
Four 10/100/1000 Mbps Ethernet interfaces
6 USB 3.1 Gen 2 ports
Four RS-232 serial interfaces
2 RS-422/485 serial interfaces
Display: HDMI 2.0 interface, support 4K resolution.
Power supply: Support AC 100-240V, 50/60Hz, DC 12V to 48V.
Environmental requirements:
Operating temperature: -55°C to +105°C
Storage temperature: -65°C to +150°C
Vibration: 10g, 5-500Hz
Impact: 50g, 11ms
Application field
The VMIVME-4150 is suitable for applications that require high performance computing and data acquisition, including but not limited to:

Aerospace: Used in satellite data processing and flight control systems.
Military electronics: Signal processing for radar and communication systems.
Scientific research: Used for particle physics experiments and astronomical observation data analysis.
Industrial automation: for robot control and production line data acquisition.
